PD39X Pressure differential transmitter

PD39X Differential pressure transmitter for neutral or aggressive media
Measuring range up to 300 bar
Process temperature -40...+100°C
Atex approval on request
Accuracy ±0,05 %FS

In applications with a differential pressure 5% higher than the maximum standard pressure range, differential pressure measurement with two absolute pressure sensors offers greater advantages over conventional methods of differential pressure measurement.
The PD39X series Differential Pressure Transmitters do not measure the differential pressure directly but use two absolute pressure sensors to detect the measurement indirectly.
Each side of the pressure has two connection ports allowing the PD39X to be used easily in pressure lines. In this way it is also possible to measure the differential pressure exactly if the ratio standard pressure range/differential pressure is high.
All reproducible pressure sensor errors (i.e. non-linearity and temperature dependencies) are completely eliminated thanks to the mathematical error compensation.
The sensor signals are measured with a 16-bit A/D converter making it possible to measure individual standard pressure ranges with an accuracy of 0.05%FS over the entire pressure and temperature range.

The transmitters are equipped with a two-wire RS485 semi-duplex interface, compatible with the bus system that takes the "MODBUS RTU" as a model.
RIELS offers interface converters to RS232 or USB to be used for this purpose.
The READ30/PROG30 program and protocol are available free of charge.

The interface offers the following functions:

Reading of the pressure and temperature values for both sensors allowing to read not only the differential pressure but also the two standard pressure ranges.
Calibration of null points and amplification.
Graduation of the analog output with respect to different pressure ranges or different units of measure.
Configuration settings such as measurement frequency, low pass filter (LP), bus address, etc.
Reading of information such as serial number, compensated pressure and temperature ranges, etc.

Price per Unit

€561.00(Vat excluded)
€684.42(Vat included)
Qty Unit price
(Vat excluded)
Unit price
(Vat included)
1 €561.00 €684.42
Availability
20 working days
Quantity
CONFIGURE THE PRODUCT

In this section you will find all the variants available for this model, improve your configuration with the drop-down menus below, select the desired quantity and click on "ADD TO CART or REQUEST A QUOTE"

The price displayed refers to a specific configuration and changes based on the variants selected.
The configuration follows an indicative order. Configure the product according to your needs.
