RIL150 Immersion Level Transmitter

RIL150 Immersion Level Transmitter

RIL150 Immersion level transmitter suitable for chemically aggressive liquids.

Measuring range 0,5...50 mtH2O

Process temperature 0...+50°C

Protection degree IP68

Atex approval Only safe zone

The RIL150 is a submersible level transmitter designed to measure liquid levels in aggressive environments. Equipped with a durable plastic probe and a ceramic sensor, the RIL150 offers accurate and reliable measurement. Its applications include wastewater treatment and other situations where liquids can be corrosive.

The RIL150 is available in several measurement ranges, and offers a typical accuracy of 0.1% FSO. It is calibrated and compensated for temperature, ensuring stable performance even under changing conditions. Robust PP, PVDF or PTFE construction ensures long service life and resistance to chemicals.

Output options of the RIL150 include 4-20mA, I2C, MODBUS and HART, making the transmitter compatible with a wide range of control and monitoring systems.

ORDER CODE:
RIL150-A-04-G-42-C3-010-H3-A2

Price per Unit

€234.00(Vat excluded)

€285.48(Vat included)

Qty	Unit price (Vat excluded)	Unit price (Vat included)
1	€234.00	€285.48
5	€210.00	€256.20
10	€199.00	€242.78

Availability

25 working days

Quantity

Can't find the right configuration? Ask for a quote.

Print product sheet

CONFIGURE THE PRODUCT

In this section you will find all the variants available for this model. Improve your configuration with the drop-down menus below, select the desired quantity and click ADD TO CART

The price displayed refers to a specific configuration and varies based on the options selected.

The ordering of the variants is indicative: customize the configuration according to your needs.

Principle of measurement

Cable material

Maximum measurable level

Length of the connecting cable

Body material

Output details

Accuracy

Product features
Principle of measurement	Piezoresistive
Informations measured	Level
Detection type	Continuous measurement
Measurable media	Aggressive Liquids, Petrochemical products
Explosion protection	Safe zone
Minimum process fluid temperature	0 °C
Maximum process fluid temperature	50 °C
Maximum measurable level	5 m
Mounting	From the top
Measurement site	Channel, Sink, Tank
Measurement type	With contact
Storage temperature	0...+50°C
Ambient temperature	0...+50°C
Properties of the fluid	Aggressive
Details of the signal inputs and outputs
All signal outputs available	4...20 mA, Modbus RTU, 0...10 Vdc, 0...5 Vdc, 1...5 Vdc, 0,5...4,5 Vdc
Signal Output Type	Current
Output details	1 x Analog 4…20mA
Registry features
Display	No
Electrical data
Voltage type	24 Vdc
Type of electrical connection	Cable
Cable material	PTFE (TEFLON®) - Polytetrafluoroethylene
Reverse polarity protection	No
Degree of protection	IP68
Length of the connecting cable	10 m
Insulation resistance	100 MΩ@ 100VDC
Operating voltage	2-wire 12…30 Vdc
Mechanical data
Materials in contact with the measured fluid	CERAMIC - Ceramics, PTFE (TEFLON®) - Polytetrafluoroethylene
Diaphragm material	CERAMIC - Ceramics
Oil filling	None
Body material	PTFE (TEFLON®) - Polytetrafluoroethylene
Impact protection	100 g(10ms)
Vibrations resistance	20 g RMS(20 to 2000Hz)
Height	125 mm
Width	32 mm
Depth	32 mm
Performance data
Accuracy	±0,25% Full scale
Compensated temperature range	0...50°C
Temperature coefficient zero point	±0,75[Typ.], ±1.5[Max]
Temperature coefficient span	±0,75[Typ.], ±1.5[Max]
Long-term stability	±0,2% of the Scale Fund
Approvals
Naval approvals	None
Food / pharmaceutical approvals	None
Atex approvals	None
Standards and Certifications	RoHS, Directive 2014/35/EU “Low voltage Directive”, Directive 2014/30/EU “Electromagnetic compatibility Directive”
EMC applied harmonized standards	EN 61000-6-3:2007, EN 61000-6-2
CE omologation	Yes
Low voltage applied harmonized standards	EN 61010-1: 2010
Rohs applied harmonized standards	EN IEC 63000:2018
Logistics
Type of packaging	Carton BOX
Contains batteries	No
country of origin	PRC
Customs Code	9026202090
Gross weight	1,1 kg
Net weight	0,8 kg
Packaging volume	0,007 m³
Packing length	26 cm
Packaging width	21 cm
Packaging depth	13 cm
