RIL850-1X Capacitive level sensor

RIL850-1X Capacitive level sensor suitable for non-conductive liquids. Uncoated electrode. Up to 100 mm
Measuring range up to 100 mm
Process temperature up to 200°C
Atex approval on request
Electrode type short bar uncoated

The Capacitive Level Sensors from the RIL850 series are versatile devices designed for monitoring the limit level of liquids and bulk solids in a wide range of industrial applications. These sensors offer a wide range of distinctive features that make them ideal for precise monitoring of material levels in tanks, containers, pipes, silos, and hoppers.

One of the key features of RIL850 sensors is their universality of use. They can be directly mounted in various environments, regardless of the nature of the materials or the type of container.

The configuration and setup of the sensors are simplified through the use of a magnetic pen, enabling quick installation without the need for fluid presence. Additionally, RIL850 sensors provide optical indication through two LEDs, further simplifying level monitoring.

A significant strength of RIL850 sensors is their high stability with high sensitivity, making them suitable for use with materials characterized by a dielectric constant (εr) equal to or greater than 1.3.

To adapt to various needs, RIL850 sensors are available in various configurations, including versions with coated electrodes for the detection of adhesive, aggressive, or conductive fluids. Furthermore, there are options for high-temperature applications and for use in hazardous environments, including explosion-proof and intrinsically safe versions.

Price per Unit

€184.00(Vat excluded)
€224.48(Vat included)
Qty Unit price
(Vat excluded)
Unit price
(Vat included)
1 €184.00 €224.48
Availability
25 working days
Quantity
CONFIGURE THE PRODUCT

In this section you will find all the variants available for this model, improve your configuration with the drop-down menus below, select the desired quantity and click on "ADD TO CART or REQUEST A QUOTE"

The price displayed refers to a specific configuration and changes based on the variants selected.
The configuration follows an indicative order. Configure the product according to your needs.
