VZB-10-PP-AN-F Oval gear flow meter - 97478820

VZB-10-PP-AN-F Oval gear flow meter for Acid and Alkaline Liquids
Measuring range 0,1...10,0 l/min
Process temperature -10...+65 °C
Signal output Analog 4-20 mA + Pulses - 450 pulses/lt
Process pressure -0,8...10 bar

The proposed sensor is a highly versatile device designed for monitoring and dosing a wide range of fluids compatible with PP, FKM, and PTFE materials. Its ability to adapt to viscosities ranging from 2 to 1000 mPas makes it a reliable choice for various applications. Equipped with advanced electronics, the sensor is capable of providing an analog current signal as an output, allowing for easy integration with other control and data recording systems.

In addition to its basic functionalities, this instrument offers some additional features that set it apart. Its resistance to a maximum pressure of 20 bar ensures safe and reliable operation even under high-pressure conditions. Moreover, it can operate at temperatures up to a maximum of 65°C, allowing for use in high-temperature environments.

The maximum flow rate of 10 l/min ensures accurate measurement and controlled distribution of fluids. In the version with pulse launcher, the maximum flow rate corresponds to 450 imp./L, offering increased flexibility and precision for specific applications.

One notable feature of this sensor is its compatibility with aggressive liquids such as acids, alkalines, and other chemically corrosive fluids. This makes it an ideal choice for industrial applications that require monitoring and dosing of such substances.


Price per Unit

€652.00(Vat excluded)
€795.44(Vat included)
Qty Unit price
(Vat excluded)
Unit price
(Vat included)
1 €652.00 €795.44
25 working days

In this section you will find all the variants available for this model, improve your configuration with the drop-down menus below, select the desired quantity and click on "ADD TO CART or REQUEST A QUOTE"

The price displayed refers to a specific configuration and changes based on the variants selected.
The configuration follows an indicative order. Configure the product according to your needs.
