HD49 Temperature, humidity, and Dew point transmitters

HD49 Temperature, Humidity and Dew Point Transmitters. ;0÷10V;serial RS485 MODBUS-RTU.
Measuring range up to 100% UR | Up to 150°C
Protection degree IP66
Atex approval Only safe zone
Signal output 4÷20 mA

The HD49 series transmitters are used for temperature, relative humidity and dew point control in the HVAC/BEMS (Heating, Ventilation, Air Conditioning/Building Energy Management System) sector in various applications, such as pharmaceutical, museum , clean rooms, ventilation ducts, industrial and civil sectors, crowded places, cellars, auditoriums, gyms, animal farms and greenhouses.

These transmitters are available with passive 4÷20 mA analogue output.

Some versions have only a standard analogue output, suitable for transmission to a remote viewer, recorder or PLC.
Other versions only have an RS485 serial output, suitable for connection to a PC or PLC.
Relative humidity is measured via a temperature-compensated capacitive sensor, which ensures precise and reliable measurements over time.

The models are available with two probe temperature ranges: standard (-20°C to +80°C) and extended (-40°C to +150°C) for more critical applications.
The sensors are protected by a 10 μm stainless steel filter to prevent the ingress of dust and particles (other types of filters are available for different applications).
Transmitters are factory calibrated and require no further adjustments by the installer.

ORDER CODE:
HD49-07TO1L

Price per Unit

€270.00(Vat excluded)
€329.40(Vat included)
Qty Unit price
(Vat excluded)
Unit price
(Vat included)
1 €270.00 €329.40
Availability
20 working days
Quantity
CONFIGURE THE PRODUCT

In this section you will find all the variants available for this model, improve your configuration with the drop-down menus below, select the desired quantity and click on "ADD TO CART or REQUEST A QUOTE"

The price displayed refers to a specific configuration and changes based on the variants selected.
The configuration follows an indicative order. Configure the product according to your needs.
