M9.02.P/W Remote Viewer

M9.02.P/W Monitor for remote flow measurement and control
M9.02.P/W Remote Viewer
ORDER CODE:
 M9.02.P1
Protection degree IP65
Signal output Analogy 4...20 mA + Pulses
Mouting Panel or wall-mounted
Display Color LCD

The M9.02.P/W is a remote display used to convert the frequency signal of FLS instruments into an instantaneous range value.

Equipped with a large 4-inch graphical display that clearly shows measured values and other useful information, color backlighting makes it easy to determine measurement status even from a distance. Software provides assistance to reduce errors and quickly configure all parameters.

Calibration can be done by tweaking the setup functions or using a reference value with the new "in-line calibration." In addition, a 4...20 mA output is available to communicate the flow rate to an external remote device, and a suitable combination of digital outputs allows the configuration to be customized to control any process.

There is in addition a USB port for updating the firmware.

ORDER CODE:
 M9.02.P1

Price per Unit

€482.00(Vat excluded)
€588.04(Vat included)
Qty Unit price
(Vat excluded)		 Unit price
(Vat included)
1 €482.00 €588.04
Availability
25 working days
Quantity
Buy
Print product sheet
CONFIGURE THE PRODUCT

In this section you will find all the variants available for this model, improve your configuration with the drop-down menus below, select the desired quantity and click on "ADD TO CART or REQUEST A QUOTE"

The price displayed refers to a specific configuration and changes based on the variants selected.
The configuration follows an indicative order. Configure the product according to your needs.
