VTC/VIC Digital display

VTC/VIC Local display with analog and digital output for volumetric flow and temperature measurement
Protection degree IP65
Signal output 4...20 mA + NAMUR or Push/Pull
Atex approval on request
Accuracy ± 1.5 of the read value

The VTC/VIC displays can be configured with a carrier frequency or inductive sensor for volumetric flow assessment. Depending on the version, it can be installed in various explosive atmospheres.

The displays feature a graphic screen that allows direct on-screen display of all measurement results and relevant process parameters. These settings can be modified using the four membrane keys. The display brightness can be adjusted to ensure good visibility.

The VTC/VIC displays also offer an integrated interface that allows setting operating parameters and reading measured values using the CON.USB interface adapter and "KEM EasyControl" visualization software. This interface can be configured as either HART or USB, depending on the requirements.

The display housing is designed to be rotatable by 360°, enabling easy viewing of results from any position. Additionally, there are programmable control inputs and two status LEDs to provide visual information on the device's operation.

ORDER CODE:
VTC-K-K-H-P-Ex

Price per Unit

€1,070.00(Vat excluded)
€1,305.40(Vat included)
Qty Unit price
(Vat excluded)
Unit price
(Vat included)
1 €1,070.00 €1,305.40
Availability
25 working days
Quantity
CONFIGURE THE PRODUCT

In this section you will find all the variants available for this model, improve your configuration with the drop-down menus below, select the desired quantity and click on "ADD TO CART or REQUEST A QUOTE"

The price displayed refers to a specific configuration and changes based on the variants selected.
The configuration follows an indicative order. Configure the product according to your needs.
