VZB-5-PP Oval gear flow meter - 96010455

VZB-5-PP Oval gear flow meter for acid liquids
Measuring range 0,1...5,0 l/min
Process temperature -10...+80°C
Signal output NPN - 450 p/lt
Process pressure -0,8...10 bar

The VZB  gear sensor, thanks to the FKM seals and the impeller couple plus the body of the PP instrument, can be used in monitoring the flow rates of acid liquids.

The volumetric sensor works in a temperature range from -10 °C up to 80 °C and withstands a maximum pressure of 10 bar. This instrument is capable of processing up to 5 l/min.

Repeatability of ±0.5% and accuracy of ±1% can be improved by performing a field calibration by changing the calibration factor.

The sensor is powered at 24 Vdc and the output signal is NPN type.

For use, a close-mesh filter of approximately 200 mesh is recommended to avoid compromising the internal helix and it is essential to maintain straight sections before and after the installation of the sensor to ensure accuracy and repeatability.


Price per Unit

€322.00(Vat excluded)
€392.84(Vat included)
Qty Unit price
(Vat excluded)
Unit price
(Vat included)
1 €322.00 €392.84
25 working days
