Thanks to the FKM seals, the stainless steel impeller and the aluminum body of the instrument, the VZS gear sensor can be used to monitor the flow rates of grease, oils and vegetable oils.
The volumetric sensor works in a temperature range from -20 °C up to 100 °C and withstands a maximum pressure of 25 bar. This instrument is capable of processing up to 0.3 l/min.
Repeatability of ±0.5% and accuracy of ±1% can be improved by performing a field calibration by changing the calibration factor.
The sensor is powered at 24 Vdc and the output signal is NPN type.
For use, a close-mesh filter of approximately 200 mesh is recommended to avoid compromising the internal helix and it is essential to maintain straight sections before and after the installation of the sensor to ensure accuracy and repeatability.
97479339
Price per Unit
Qty | Unit price (Vat excluded) |
Unit price (Vat included) |
---|---|---|
1 | €305.00 | €372.10 |
