HM-TRI Turbine flow meters

HM-TRI Turbine flowmeters with tri-clamp process connection
Measuring range up to 400 lt/min
Process temperature Up to 150°C
Process pressure up to 16 bar
Accuracy ± 0,1%

The HM-TRI turbine flow meter series is used to measure continuous and discontinuous flow rates. They are primarily employed for measuring the flow of water, alcohol, disinfectants, and detergents in the pharmaceutical and food sectors.

These flow meters are particularly suitable for various applications, including consumption measurement, dosing, and process control. Their versatility allows for precise monitoring of the consumption of substances such as pharmaceutical liquids, ultrapure water, alcohol, disinfectants, and cleaning agents.

Only high-quality steels and materials that can withstand corrosive liquids are used in the production of turbine flow meters. Combined with the innovative flushable PTFE bearings, the HM-TRI ensures excellent measurement accuracy in compliance with all common material specifications in the pharmaceutical sector. The design is free from dead spaces and can be cleaned in place (CIP), thus meeting the highest hygiene standards.

The instrument is equipped with a Tri-clamp fitting compliant with DIN 32676, making it suitable for connection to pipes that adhere to the DIN 11866 series A standard.

Short response times, highly dynamic performance, and high measurement accuracy ensure precise regulation and control of flow rates in the most demanding applications.

ORDER CODE:
HM-003-TRI

Price per Unit

€2,965.00(Vat excluded)
€3,617.30(Vat included)
Qty Unit price
(Vat excluded)
Unit price
(Vat included)
1 €2,965.00 €3,617.30
Availability
25 working days
Quantity
CONFIGURE THE PRODUCT

In this section you will find all the variants available for this model, improve your configuration with the drop-down menus below, select the desired quantity and click on "ADD TO CART or REQUEST A QUOTE"

The price displayed refers to a specific configuration and changes based on the variants selected.
The configuration follows an indicative order. Configure the product according to your needs.
