LEO-RECORD Digital manometer datalogger

LEO-RECORD Pressure gauge with recording function. Up to 1000 bar
Measuring range up to 1000 bar
Process temperature -40...+85°C
Atex approval on request
Accuracy ±0,1 %FS
LEO-RECORD is a self contained battery powered instrument with digital display designed to record pressure and temperature over extended time intervals.
Through the RS485 interface the data logger can be connected to a computer for configuration and for acquiring the recordings.
Comes complete with software and accessories.

Advantages

  • High measurement accuracy, resolution and robustness
  • High data security through the use of a non-volatile memory
  • Display of current pressure and recording status
  • Recording of pressure and temperature
  • Simple and well structured configuration and data reading software (Logger 4.x) for PC or PDA
  • The combination of event-controlled logging with interval logging prevents unnecessary data logging (i.e. you only log pressure changes…)
  • The installation data (and comments) of the measuring station can be stored in the instrument
  • Pressure is measured and displayed once per second (shortest interval). The upper part of the display indicates the current pressure, the lower part of the display shows the recording status.
  • All versions of LEO-RECORD have two operating buttons.
  • The left key is used to turn on the instrument and to select the functions and units of pressure measurement.
  • The right key executes the selected function or unit of measure.

Functions

  • Possibility to select numerous pressure units
  • 5 custom pressure units, configurable via software
  • Zero point adjustment via buttons
  • The «Record» function can be started and stopped manually
  • Ability to configure different recording functions

Options

  • Other compensated pressure ranges
  • Other compensated temperature ranges
  • Parts in contact with the middle finger in Hastelloy, Inconel 718 or titanium
  • Custom front caps
  • Custom firmware with calculations for specific applications (e.g. leak measurement)
  • Other materials gasket for pressure transducer
  • Other oil fillings for pressure transducer
  • Protective rubber coating
  • Carrying case

Price per Unit

€668.00(Vat excluded)
€814.96(Vat included)
Qty Unit price
(Vat excluded)
Unit price
(Vat included)
1 €668.00 €814.96
Availability
30 working days
Quantity
CONFIGURE THE PRODUCT

In this section you will find all the variants available for this model, improve your configuration with the drop-down menus below, select the desired quantity and click on "ADD TO CART or REQUEST A QUOTE"

The price displayed refers to a specific configuration and changes based on the variants selected.
The configuration follows an indicative order. Configure the product according to your needs.
